Overview

Formal integrates with Business Intelligence applications to enable end-user identity propagation. This ensures that queries from BI tools are attributed to the actual end-user rather than a shared machine user, enabling accurate auditing and per-user policy enforcement.

​
How It Works

When you set up a BI integration:
  1. Sync: Formal Control Plane synchronizes with your BI application to fetch user identities
  2. Map: External IDs are automatically assigned to your Formal users
  3. Propagate: When BI tool users execute queries, their identity is passed to the Connector
  4. Enforce: Policies evaluate based on the end-user, not the BI tool’s machine user
The Connector automatically fetches user information from the Control Plane, so no additional configuration is needed in your Connector deployment.

​
Supported BI Applications

Supported BI tools
  • Metabase
  • Looker
  • Tableau
  • Power BI
  • Custom applications (via SQL commenter)

​
Setup

​
Metabase

1

Navigate to BI Integrations

Go to BI Applications in the Formal console
2

Add Integration

Click Add New App
3

Select Metabase

Choose Metabase from the list
4

Enter Credentials

  • Server Hostname: Your Metabase instance URL - Admin Username: Metabase admin username - Admin Password: Metabase admin password
5

Allow-list IPs

If your Metabase instance has IP restrictions, allow-list these IPs: - 52.18.34.8 - 52.51.88.92 - 54.72.150.112
When connecting Metabase, the admin user will receive a “We’ve Noticed a New Metabase Login” email alert from a location in Ireland (where Formal’s workers run).

​
Terraform

resource "formal_integration_bi" "metabase" {
  name = "production-metabase"

  metabase {
    hostname = "metabase.example.com"
    username = "admin@example.com"
    password = var.metabase_admin_password
  }
}

​
Looker

Looker supports end-user identity propagation via JDBC connection parameters.
1

Open Database Connection

Go to Admin → Connections in Looker
2

Edit Connection

Select your database connection
3

Add Parameter

In the “Additional Params” section, add:
options=formal_enduser={{ _user_attributes['email'] }}
4

Save

Save the connection settings
This configuration tells Looker to pass the end-user’s email in the connection string, which Formal extracts and uses for policy evaluation.

​
Custom Applications

For internal applications or custom BI tools, use the formal-sqlcommenter library to propagate end-user identity.

​
Python/Django

Install the package:
pip install formal-sqlcommenter
Use in your application:
from formal_sqlcommenter import add_sql_comment
import psycopg2

# Connect as machine user
conn = psycopg2.connect(
    host="connector.joinformal.com",
    port=5432,
    user="idp:formal:machine:my_app",
    password="machine_user_token",
    database="production_db"
)

# Add end-user ID to queries
cursor = conn.cursor()
query = "SELECT * FROM users WHERE id = %s"

# This query will be attributed to the human user
commented_query = add_sql_comment(
    query,
    external_user_id="katie@example.com"  # End-user's Formal external ID
)

cursor.execute(commented_query, (123,))

​
Configuring External IDs

External IDs map end-users in external systems to Formal users.
1

Create Formal User

Ensure a Formal user exists for the BI tool user
2

Add External ID

In the Formal user details page, add the user’s ID from the BI tool For example, if Katie’s Looker user ID is 12345, add 12345 as an external ID to Katie’s Formal user
3

Verify

Check Logs to confirm queries are attributed to the correct end-user

​
Automatic Sync

For Metabase and other integrated BI tools, Formal automatically:
  1. Fetches user lists from the BI application
  2. Matches them to Formal users by email
  3. Assigns external IDs
No manual configuration needed!

​
Policy Examples

​
End-User Access Control

package formal.v2

import future.keywords.if
import future.keywords.in

# Block if end-user (not machine user) lacks access
session := {
  "action": "block",
  "type": "block_with_formal_message",
  "message": "You do not have permission to access this resource",
  "reason": "End-user not in approved group"
} if {
  # Connection is from BI tool (machine user)
  input.user.type == "machine"

  # End-user is not in analyst group
  not "analyst" in input.end_user.groups
}

​
Per-User Data Masking

package formal.v2

import future.keywords.if
import future.keywords.in

# Mask PII unless end-user has special access
post_request := {
  "action": "mask",
  "type": "nullify",
  "columns": pii_columns
} if {
  # Identify PII columns
  pii_columns := [col |
    col := input.row[_]
    col["data_label"] in ["email", "ssn", "phone"]
  ]

  count(pii_columns) > 0

  # End-user doesn't have PII access
  not "pii_access" in input.end_user.groups
}

​
Audit BI Tool Access

package formal.v2

import future.keywords.if

# Log all BI tool queries with end-user context
pre_request := {
  "action": "allow",
  "reason": "BI tool query logged",
  "contextual_data": sprintf(
    "BI User: %s, Tool: %s, Query: %s",
    [input.end_user.email, input.user.username, input.query.query]
  )
} if {
  input.user.type == "machine"
  startswith(input.user.username, "idp:formal:machine:")
}

​
Monitoring

​
View End-User Attribution

  1. Navigate to Logs
  2. Filter by machine user (BI tool)
  3. Check “End User” column to see attributed end-users
  4. Verify queries are attributed correctly

​
Session Details

In Sessions, you’ll see:
  • User: Machine user (BI tool)
  • End-User: Actual human user in the BI tool
  • Queries: Full query history with end-user attribution

​
Troubleshooting

Possible causes: - BI integration not set up - External IDs not mapped - BI tool not passing end-user information Solution: 1. Verify BI integration is active in Formal console 2. Check Formal user has external ID matching BI tool user ID 3. For Looker, verify JDBC parameters are configured 4. Review Connector logs for end-user extraction errors
Possible causes: - Incorrect admin credentials - IP allow-list blocking Formal workers - Metabase instance not reachable Solution: 1. Verify admin credentials are correct 2. Allow-list Formal worker IPs (see above) 3. Check Metabase logs for authentication attempts 4. Ensure Metabase instance is publicly accessible or VPN-accessible by Formal
Possible causes: - Policy references input.user instead of input.end_user - End-user not in expected groups Solution: 1. Update policies to use input.end_user for BI tool queries 2. Verify end-user’s group memberships in Formal console 3. Test policy in dry-run mode and review logs

​
Best Practices

For BI tools, write policies that evaluate input.end_user attributes, not input.user (which is the machine user).
Use end-user attributes to filter results, ensuring each BI user only sees data they’re authorized to access.
Regularly review logs to ensure end-user attribution is working and no queries are misattributed.
For integrated BI tools, Formal syncs user lists automatically. For custom apps, update external IDs when users are added/removed.

​
Next Steps

Configure External IDs

Map BI users to Formal users

Write Policies

Create end-user-based policies

View Logs

Monitor end-user queries
